Description

MADE FOR FUN

The Marin Rift Zone is your ultimate do-it-all trail bike, made to party on any terrain. With modern geometry and 140/130mm of travel, it's your ideal partner for all-day epics, local shred laps, and big mountain adventures. Get ready for endless fun!

TRAIL-READY

The Marin Rift Zone's MultiTrac suspension and modern geometry deliver a playful, balanced ride. A wide-range 1x drivetrain and steep seat angle make climbs a breeze, while the dropper post, progressive air suspension, and slack head angle inspire confidence on descents.

FRAME FEATURES

Wheel size fit! Smaller sizes get nimble 27.5" wheels, while larger frames roll on confidence-inspiring 29" wheels. Medium riders have the choice! Better yet, the Rift Zone 1 is also available in an XS size, perfect for growing shredders! The frame is also upgradable from 141mm hubs to boost 148mm and to the SRAM UDH!

WHERE IT BEGAN!

Marin's roots are tangled with the very beginnings of mountain biking. Founded in Marin County, California, the sport's birthplace, This rich heritage fuels their passion to this day. Now, Marin pushes those boundaries further with riders like Matt Jones, constantly innovating to redefine what's possible on a mountain bike

X-FUSION SUSPENSION

The X-Fusion Slide/Sweep fork offers 140mm of air-sprung suspension with compression and rebound adjustment, while the O2 Pro R air shock manages the 130mm of rear travel with rebound adjustment.

SHIMANO DEORE 1X11 DRIVETRAIN

The massive 11-51t cassette provides a similar range to more expensive 12-speed drivetrains, giving you all the help you need to tackle the climbs!

HYDRAULIC DISC BRAKES

Powerful Tektro HD-M280 hydraulic disc brakes provide reliable stopping power and modulation, giving you confidence and control in all conditions.

DROPPER POST

Quickly adjust your saddle height on the fly for improved control and confidence on descents and technical sections. XS/S features 150mm of drop while M-XL uses 170mm.

TUBELESS READY

Grip for days, punctures begone! These rims come pre-taped from the factory, so ditch the tube, add valves and sealant, and experience the ultimate grip of the ultra-tacky Vee Snap tyres with their Top 40 Compound.

Components

FRAMESET
FRAME
Series 3 6061 Aluminium, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs
HEADSET
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SUSPENSION
FORK
X-Fusion Slide (29") or Sweep (27.5") Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
SHOCK
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
DRIVETRAIN
REAR DERAILLEUR
Shimano Deore, 11-Speed, SGS
SHIFTER
Shimano Deore, SL-5100R, 11-Speed
CRANK
Marin Forged Alloy, Boost Spacing
CHAINRING
Integrated Steel 32T Narrow Wide Chainring
CASSETTE
Sunrace, 11-Speed, 11-51T, ED Black
CHAIN
KMC X-11 Silver and Black
BRAKES
FRONT BRAKE
Tektro HD-M280 Hydraulic, 180mm Rotor
REAR BRAKE
Tektro HD-M280 Hydraulic, 180mm Rotor
WHEELS
REAR HUB
Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body
RIM
Marin Aluminium Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
TYRE
Vee Tire Co. Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible
CONTACT POINTS
HANDLEBAR
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
GRIPS
Marin MTN, Closed End
SADDLE
Marin Speed Concept
SEATPOST
X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm
STEM
Marin 3D Forged Alloy, 35mm
PEDALS
NOT INCLUDED
WEIGHT
BIKE WEIGHT
14.6kg (Size L)

Note: For a complete tubeless setup, valves and sealant must be purchased separately.

*Specs subject to change based on availability.

Geometry

Frame Size XS (27.5")
S
(27.5")
M
(27.5")
M
(29")
L
(29")
XL
(29")
Height (cm) 155-163cm 163-170cm 168-175cm 170-177cm 177-185cm 185-192cm
(A) Frame stack 569.1 600.7 605.2 605.2 637.3 641.8
(B) Frame reach 415 430 450 460 485 515
(C) Head tube angle 65.5° 65.5° 65.5° 65.5° 65.5° 65.5°
(D) Head tube length 115 120 125 115 125 130
(E) Seat tube angle 77° 77° 77° 77° 77° 77°
(F) Seat tube length 330 390 400 400 425 430
(G) Effective top tube 552.6 568.7 589.7 605 632.1 663.2
(H) BB Height 339 339 339 339 343 343
(I) BB offset (Drop) 35 35 35 35 35 35
(J) Chainstay length 430 430 430 430 430 430
(K) Wheelbase 1147.8 1164.8 1186.9 1205.1 1234.4 1266.3
(L) Standover height 661.7 677.8 687.8 691.2 701.7 700.5
Handlebar Width 780 780 780 780 780 780
Stem Length 35 35 35 35 35 35
Crank Length 170 170 170 170 170 170
Fork Offset 44 44 44 44 44 44
Seatpost Diameter 30.9 30.9 30.9 30.9 30.9 30.9


* All lengths in mm

Assembly

Step 1

Rift Zone 1 - Assembly Instructions

Step 2

How To Unbox Your Dual Suspension MTB

Step 3

How To Setup Your Suspension

Step 4

Dial In Your Bike Fit

Step 5

Dial In Your Tyre Pressures

Step 6

Pre-Ride Check
